Round led downlight



Light Source	LED
Item Type	Downlights
LED Light Source	Epistar
Warranty(Years)	3
Input Voltage(V)	AC85-264V/DC24V
Lamp Power(W)	7
Lamp Luminous Flux(lm)	500
Lamp Luminous Efficiency(lm/w)	72
Color Temperature(CCT)	3300-9500K
Working Temperature(℃)	-25 - +65
Working Lifetime(Hour)	50000
Lamp Body Material	Aluminum Alloy
IP Rating	IP44
Certification	CE, FCC, RoHS
Model Number	LDM-R180
Place of Origin	Guangdong, China (Mainland)
Brand Name	lightingme
color:	(cool,warm,natural)white RGB
Color	White
Life	50,000h
Input Voltage	DC24V
Light Dim	Dia-141mm
Dimension	Dia180*18mm
Dim for installation	Dia170mm
Packing size	310*230*50mm
Weight	0.8Kg

Features of the Products

• Energy saved up to 50%. high intensity
• 5-years life span
• Special different view angles, mixing lighting design
• Instant start, no flickering, no humming
• New inner high efficiency (95%) With heat protection system, the constant current driver can work under unstable voltage.
• Special circuit design, each LED can work separately thus  it can avoid the influnence that a  broken LED causes.
• No electric wave.
• No such hazard that mercury or lead enters the environment
• No RF interference
• luminous efficacy:70lm/W; (Pure White )
• High power led light panel with LED type : SMD 3528 LEDS /SMD 3014
• Installation of LED panel light: Convenient and efficient, both catenary & push-in type are available.

 Technology parameter

1. Thickness:14mm

2. Size:Dia180mm

3. Lumens efficacy:  70lm/w

4. Input voltage:AC100~240V

5. Lumen:700lum

6. Lifespan:≥50,000h

7. Color Temperature:3000-9500K

8. Power consumption:10W

9. Certificate:CE,RoHS,FCC approved, with 3 year quality warranty.

Applications

*Hotels

*Conference / Meeting rooms

*Factories & Offices

*Commercial Purposes.

*Residential / Institution Buildings

*Schools, Colleges & Universities

*Hospitals

*Places where energy saving and high color rendering index lighting are needed

 Warranty and Aftersales Services:

• All products we sell are in good quality and under strict examination before they are shipped.
• We will try our best to avoid any quality problem.Your problems will be give the solution in 24 hours.
• Warranty for quality is 3 years and we will repair or replace defective goods in next order

Packing List:

1. LED Downlight 1Piece
2. LED constant current driver 1Piece
3. DC24V constant voltage power adapter 1Piece
